Executive summary: In Belgium, a collaborative effort between regional and federal authorities has led to the creation of a unified service that aggregates all Belgian addresses into a comprehensive dataset. This dataset is called BeStAddress.

Address lookup - Part 2b: Messing around

This post is a continuation of the previous post where we have analyzed the data model of the BeStAddress dataset.

Introduction

In Belgium, each municipality is responsible for naming its streets. Although it is recommended to avoid similar street names, this can sometimes result in two streets within the same municipality having very similar names. In this post, we will explore the BeStAddress dataset to identify pairs of streets with similar names that are geographically close to each other.

To analyse this, we will use the unified table that aggregates all the data from the different regions of Belgium to find pairs of streets with similar names that are close to each other.

We will proceed in three steps:

Find the average latitude and longitude of each street in each municipality.
Calculate the distance between each pair of streets in the same municipality.
Calculate the Levenshtein distance between the street names of each pair of streets.

Step 1: Find the average latitude and longitude of street in each municipality

This step will allow us to identify the geographical center of each street in the dataset and then use this information to calculate the distance between pairs of streets.

sql

WITH averages_by_streets AS (
      SELECT municipality_id,
             street_id,
             round(AVG(latitude), 4) AS latitude,
             round(AVG(longitude), 4) AS longitude,
      FROM bestAddress
      GROUP BY municipality_id, street_id
  )
SELECT * FROM averages_by_streets

Step 2. Distance Calculation

We will calculate the distance between each pair of streets in the same municipality. We will use the Haversine formula to calculate the distance between two points on the Earth's surface given their latitude and longitude.

After calculating the distance between each pair of streets, we will filter the results to only include pairs of streets that are less than 5 kilometers apart.

sql

WITH averages_by_streets AS (
      SELECT municipality_id,
             street_id,
             round(AVG(latitude), 4) AS latitude,
             round(AVG(longitude), 4) AS longitude,
      FROM bestAddress
      WHERE postcode = '4140' -- Filter by municipality_id == Sprimont
      GROUP BY municipality_id, street_id
  ),
combination_streets AS (
    SELECT a.municipality_id AS municipality_id_1,
           a.street_id AS street_id_1,
           a.latitude AS lat1,
           a.longitude AS lon1,
           b.municipality_id AS municipality_id_2,
           b.street_id AS street_id_2,
           b.latitude AS lat2,
           b.longitude AS lon2
    FROM averages_by_streets a
    CROSS JOIN averages_by_streets b
    WHERE 1 = 1
      AND (a.municipality_id, a.street_id) <> (b.municipality_id, b.street_id) -- Exclude self-joins
      AND (a.municipality_id < b.municipality_id
           OR (a.municipality_id = b.municipality_id AND a.street_id < b.street_id)
        )  -- Ensure unique pairs
),
distance_calculation AS (
    SELECT municipality_id_1,
           street_id_1,
           municipality_id_2,
           street_id_2,
           -- Haversine Formula
           -- 6371 is the radius of the Earth in kilometers
           -- RADIANS converts degrees to radians
           6371 * 2 * ASIN(SQRT(POWER(SIN(RADIANS(lat2 - lat1) / 2), 2) +
                                COS(RADIANS(lat1)) * COS(RADIANS(lat2)) *
                                POWER(SIN(RADIANS(lon2 - lon1) / 2), 2))) AS distance_km
    FROM combination_streets
)
SELECT municipality_id_1,
       street_id_1,
       municipality_id_2,
       street_id_2,
       round(distance_km, 2) AS distance_km
FROM distance_calculation
WHERE distance_km < 5;

Step 3. Levenshtein Distance Calculation

Finally, we will calculate the Levenshtein distance between the street names of each pair of streets. The Levenshtein distance is a measure of the similarity between two strings. It is defined as the minimum number of single-character edits (insertions, deletions, or substitutions) required to change one string into the other.

sql

WITH averages_by_streets AS (
      SELECT municipality_id,
             street_id,
             round(AVG(latitude), 4) AS latitude,
             round(AVG(longitude), 4) AS longitude,
      FROM bestAddress
      WHERE postcode = '4140' -- Filter by municipality_id == Sprimont
      GROUP BY municipality_id, street_id
  ),
unique_streetname AS (
    SELECT municipality_id,
           street_id,
           default_streetname
    FROM bestAddress
    WHERE 1=1
    AND street_id IN (SELECT street_id FROM averages_by_streets)
    AND municipality_id IN (SELECT municipality_id FROM averages_by_streets)
    GROUP BY ALL
),
combination_streets AS (
    SELECT a.municipality_id AS municipality_id_1,
           a.street_id AS street_id_1,
           a.latitude AS lat1,
           a.longitude AS lon1,
           b.municipality_id AS municipality_id_2,
           b.street_id AS street_id_2,
           b.latitude AS lat2,
           b.longitude AS lon2
    FROM averages_by_streets a
    CROSS JOIN averages_by_streets b
    WHERE 1 = 1
      AND (a.municipality_id, a.street_id) <> (b.municipality_id, b.street_id) -- Exclude self-joins
      AND (a.municipality_id < b.municipality_id
           OR (a.municipality_id = b.municipality_id AND a.street_id < b.street_id)
        )  -- Ensure unique pairs
),
distance_calculation AS (
    SELECT municipality_id_1,
           street_id_1,
           municipality_id_2,
           street_id_2,
           -- Haversine Formula
           -- 6371 is the radius of the Earth in kilometers
           -- RADIANS converts degrees to radians
           6371 * 2 * ASIN(SQRT(POWER(SIN(RADIANS(lat2 - lat1) / 2), 2) +
                                COS(RADIANS(lat1)) * COS(RADIANS(lat2)) *
                                POWER(SIN(RADIANS(lon2 - lon1) / 2), 2))) AS distance_km
    FROM combination_streets
), combination_with_distances_filtered AS (
SELECT municipality_id_1,
       street_id_1,
       municipality_id_2,
       street_id_2,
       round(distance_km, 2) AS distance_km
FROM distance_calculation
WHERE distance_km < 5
),
levenstein_distance AS (
SELECT
    municipality_id_1,
    street_id_1,
    municipality_id_2,
    street_id_2,
    distance_km,
    a.default_streetname AS streetname_1,
    b.default_streetname AS streetname_2,
    levenshtein(a.default_streetname, b.default_streetname) AS levenshtein_distance
FROM combination_with_distances_filtered
LEFT JOIN unique_streetname AS a
   ON a.municipality_id = municipality_id_1
      AND a.street_id = street_id_1
LEFT JOIN unique_streetname AS b
   ON b.municipality_id = municipality_id_2
      AND b.street_id = street_id_2
)
SELECT * FROM levenstein_distance
WHERE 1=1
   AND levenshtein_distance < 10
   AND levenshtein_distance > 0
ORDER BY levenshtein_distance, distance_km;

That's it! We have successfully identified pairs of streets with similar names that are geographically close to each other. It is a long query, but it is very powerful and can be used to identify potential issues with street names in the BeStAddress dataset.

Results

municipality_id_1	street_id_1	municipality_id_2	street_id_2	distance_km	streetname_1	streetname_2	levenshtein_distance
62100	7732983	62100	7732991	4.16	Rue de Damré	Rue de Gomzé	3
62100	7732996	62100	7733018	2.53	Rue de la Carrière	Rue de la Sablière	3
62100	7733062	62100	7733067	0.63	Rue des Fawes	Rue des Marets	3
62100	7733110	62100	7733117	3.48	Rue du Roua	Rue du Voué	3
62100	7732981	62100	7733047	4.02	Rue de Coreux	Rue de Theux	3
62100	7732981	62100	7733042	1.13	Rue de Coreux	Rue de Rouvreux	3
62100	7732961	62100	7733129	0.27	Rue Basse Lillé	Rue Haute Lillé	3
62100	7733092	62100	7733108	4.55	Rue du Coq	Rue du Pont	3
62100	7733105	62100	7762862	0.33	Rue du Pahy	Rue du Parc	2
62100	7733124	62100	7733132	4.37	Rue Ferreuse	Rue Houreuse	3
62100	7733123	62100	7733124	3.9	Rue Ferrer	Rue Ferreuse	3
62100	7733081	62100	7762862	2.6	Rue du Baron	Rue du Parc	3
62100	7733083	62100	7762862	1.66	Rue du Baty	Rue du Parc	3
62100	7733083	62100	7733105	1.99	Rue du Baty	Rue du Pahy	2
62100	7733081	62100	7733083	3.85	Rue du Baron	Rue du Baty	3

Further exploration

The BeStAddress dataset offers numerous opportunities for interesting analyses beyond just finding similar street names. Let's explore some additional queries that can help us understand the dataset better and potentially identify areas for improvement in address management.

1. Mapping Street Relationships Within Municipalities

When working with addresses, it's often useful to understand how streets are distributed within municipalities. This query helps us identify all unique pairs of streets within each municipality, which can be valuable for:

Urban planning analysis
Understanding street network connectivity
Identifying potential naming conflicts

sql

WITH DistinctStreets AS (
    SELECT
        municipality_id,
        street_id,
        round(avg(latitude), 3) AS latitude, -- Round to 3 decimal places (= ~110 meters)
        round(avg(longitude), 3) AS longitude
    FROM
        bestAddress
    GROUP BY
        municipality_id, street_id
)
SELECT
    a.municipality_id,
    a.street_id AS first_street_id,
    b.street_id AS second_street_id,
    a.latitude AS first_street_latitude,
    a.longitude AS first_street_longitude,
    b.latitude AS second_street_latitude,
    b.longitude AS second_street_longitude
FROM
    DistinctStreets AS a
JOIN
    DistinctStreets AS b
    ON a.municipality_id = b.municipality_id -- Same municipality
        AND a.street_id < b.street_id -- Ensure different street ids and avoid duplicate combinations
ORDER BY
    a.municipality_id,
    a.street_id,
    b.street_id
LIMIT 100;

The query uses a self-join technique to pair each street with every other street in the same municipality, while avoiding duplicate combinations. We round the coordinates to 3 decimal places (~110 meters precision) to simplify the data while maintaining meaningful geographical precision.

2. Analyzing Multilingual Street Name Coverage

Belgium's multilingual nature makes it essential to understand how well street names are documented in different languages. This query analyzes the completeness of street names across French, Dutch, and German:

sql

WITH DistinctStreets AS (
    SELECT
        DISTINCT municipality_id, street_id, streetname_fr, streetname_de, streetname_nl
    FROM
        BestAddress
)
SELECT
    municipality_id,
    COUNT(street_id) AS total_streets,
    (COUNT(CASE WHEN streetname_fr IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_fr,
    (COUNT(CASE WHEN streetname_de IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_de,
    (COUNT(CASE WHEN streetname_nl IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_nl
FROM
    DistinctStreets
GROUP BY
    municipality_id;

This query provides insights into:

The completeness of multilingual street naming
Potential gaps in language coverage
Areas that might need attention for complete multilingual support

3. Identifying Language Border Municipalities

Perhaps the most interesting analysis is finding municipalities that lie on language borders. These can be identified by looking for municipalities where street names aren't consistently available in all languages:

sql

WITH DistinctStreets AS (
      SELECT
          DISTINCT municipality_id, street_id, streetname_fr, streetname_de, streetname_nl, region_code
      FROM
          BestAddress
  )
  SELECT
      municipality_id,
      region_code,
      COUNT(street_id) AS total_streets,
      (COUNT(CASE WHEN streetname_fr IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_fr,
      (COUNT(CASE WHEN streetname_de IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_de,
      (COUNT(CASE WHEN streetname_nl IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) AS pct_streetname_nl
  FROM
      DistinctStreets
  GROUP BY
      municipality_id, region_code
  HAVING
      (COUNT(CASE WHEN streetname_fr IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) NOT IN (0, 100)
      OR (COUNT(CASE WHEN streetname_de IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) NOT IN (0, 100)
      OR (COUNT(CASE WHEN streetname_nl IS NOT NULL THEN 1 END) / CAST(COUNT(street_id) AS FLOAT) * 100) NOT IN (0, 100)
  ORDER BY
      region_code;

This advanced query helps identify:

Municipalities on language borders
Areas with mixed language usage
Potential inconsistencies in multilingual street naming

The HAVING clause specifically looks for municipalities where the percentage of street names in any language is neither 0% nor 100%, indicating mixed language usage. This can be particularly useful for:

Understanding linguistic diversity in different regions
Planning multilingual signage requirements
Ensuring proper address documentation in all relevant languages
